ALG-OF

Overfill Gauge Type OF Configurator

MADE TO ORDERSKU#: OF-6

$0.00

The Overfill Alert Gauge is a high level visual gauge designed to visually alert you that your AST (tank) is near full. This overfill monitor’s simple pop up mechanical design promotes easy installs, maximum durability, and low up front costs.

Type OF Standard (+...)
Type PO All Plastic (+...)
Type OF Stainless Level 1 (+...)
Type OF Stainless Level 2 (+...)
Type OF Stainless Level 3 (+...)
Overfill Alert Gauge. Galvanized Steel Rods. Aluminum Bushing. Polypropylene Plastic Float.
Overfill Alert Gauge. Peek or Kynar Rods. PVC Bushing. HDPE Plastic Float.
Overfill Alert Gauge. Stainless Steel Rods. Aluminum Bushing. Polypropylene Plastic Float.
Overfill Alert Gauge. Stainless Steel Rods. Aluminum Bushing. Stainless Steel Float.
Overfill Alert Gauge. Stainless Steel Rods. Stainless Bushing. Stainless Steel Float.
NPT - National Pipe Thread
Available Range: 6 to 30 By 1/4
Distance from top of tank to overfill alert level (measurment provided in inches)
Glass Calibration, replaces inner plastic piece of calibration with glass. Used for protection from heat, fumes, etc...
Solid Glass Calibration. Replaces all plastic on top of gauge with one thick solid glass top. Requires ALN or ALG.
None
Dalarm (+...)
Ralarm (+...)
adds a direct mounted audible alarm to the gauge
adds a remote mounted audible alarm to the gauge
RDN
ALN
ALN (+...)
PVN (+...)
ALG (+...)
PVG (+...)
PVN (+...)
PVG (+...)
PVN (+...)
ALN
ALN (+...)
PVN (+...)
ALG (+...)
PVG (+...)
ALN
ALN (+...)
PVN (+...)
ALG (+...)
PVG (+...)
RDN
ALN
ALN (+...)
PVN (+...)
ALN
ALN (+...)
PVN (+...)
ALN
ALN (+...)
PVN (+...)
Replace the Red HDPE Lock Nut with an Aluminum Lock Nut
Replace the Red HDPE Lock Nut with a PVC Lock Nut.
Replace the Red HDPE Lock Nut with an Aluminum Gauge Guard
Replace the Red HDPE Lock Nut with a PVC Gauge Guard
Replace the Red HDPE Lock Nut with a PVC Gauge Guard PVN still an option
Replace the Red HDPE Lock Nut with an Aluminum Lock Nut
Replace the Red HDPE Lock Nut with an Aluminum Gauge Guard
Replace the Red HDPE Lock Nut with a PVC Gauge Guard
Product total
Options total
Grand total
SKU: OF-6 Categories: , ,

Description

Related Products

Overfill Gauge Type OF Configurator Overview

What it is

Top mounted pop up gauge that can measure from 6 inches to 76 inches in Length. Bushing size can be 2”, 1.5” or .75”. Gauges are custom made in house to fit your application. Most Overfill Alert Gauges are between 6 inches and 12 inches. They are designed to pop up at a specific level (usually 90 percent) and warn you that the tank is almost full. Provides visual overfill warning.

Additional Options – Not Included

Audible Alarm Accessory

This add on feature can turn your mechanical gauge into an audible Hi or Lo level alarm.

LED At-A-Glance Accessory

Another add on feature. This can give your mechanical gauge remote reading capability.

Gauge Guard

A cover that protects the exposed plastic components on top of the gauge.

Replacement Parts

OF-Kit

Replaces all the top components with standard materials.

OFG-Kit

Replaces all the top components with standard materials and a glass calibration.

OFALN-Kit

Replaces all the top components with standard materials and an aluminum lock nut.

OFGALN-Kit

Replaces the top components with a glass calibration and aluminum lock nut.

Instructions for Operation

This gauge is a simple visual tool. If the red indicator rises into the viewing window, it is indicating that your tank is near full. Once installed you simply view the calibration during filling to determine when your tank is near full. The indicator is not calibrated. It simply indicates overfill or not.
